FSC-8-12K1P-BL Off-Grid Inverter – 12 kW

FSC-8-12K1P-BL is an advanced off-grid solar energy storage inverter that combines solar charging, grid charging, and pure sine wave AC output into a single system. Powered by a digital signal processor (DSP), it delivers fast response, high efficiency, and stable performance across different energy scenarios.

The inverter supports multiple working modes including PV priority, grid priority, and inverter priority, allowing flexible power management based on user needs. It also features UPS functionality with seamless switching between grid and battery power.

Designed for versatility, it supports both lithium (LiFePO4) and lead-acid batteries, with intelligent charging control and up to 250A charging capability. Dual AC outputs enable smart load distribution, while communication options like CAN, RS485, USB, and Wi-Fi allow easy monitoring and integration.

With support for parallel operation (up to 9 units), generator input, and advanced protection features, this inverter is ideal for off-grid homes, solar backup systems, and small to medium commercial setups.

Size and Other Advanced Options

Model Options:
FSC-8K1P-BL / FSC-10K1P-BL / FSC-12K1P-BL

Solar Input:
Max PV Input Power: 12kW / 15kW / 18kW
Max Input Voltage: 500V
MPPT Voltage Range: 90V – 450V
Max Input Current: 30A × 2 MPPT

AC Input (Grid/Generator):
Nominal Voltage: 230V (L/N/PE)
Voltage Range: 90V – 280V
Frequency: 50/60Hz (Auto)

Battery:
Battery Type: Li-Ion / Lead-acid
Nominal Voltage: 48V
Voltage Range: 42V – 60V
Max Charge Current: up to 250A
Max Discharge Current: up to 280A
Communication: CAN / RS485

Inverter Output:
Nominal Power: 8kW / 10kW / 12kW
Peak Power: up to 24kVA
Output Voltage: 230V
Waveform: Pure Sine Wave
Efficiency: Up to 94%
Transfer Time (UPS): 10ms

Features:
UPS Function (Grid / Battery / Inverter modes)
Dual AC Output (Smart Load Management)
Supports Parallel Operation (up to 9 units)
Generator Input Support
Wi-Fi Monitoring & Mobile App Support
USB Firmware Upgrade

Protection:
Overload Protection
Short Circuit Protection
Over/Under Voltage Protection
Over Temperature Protection
BMS Communication Protection

Physical:
Size: 625 × 400 × 120 mm
Weight: 20 kg
Cooling: Fan Cooling
Noise: ≤50dB
Protection Level: IP21

Operating Conditions:
Temperature: -10°C to 60°C
Humidity: 5% – 95% (Non-condensing)
